Custom Technical Drawings and Models for Your Application

Würth CAD Services professional performing 3D CAD drawing services

Accurate technical drawings are critical in every stage of production. More than just sketches, these documents are a kind of language that communicates the necessary information to create a functioning, reliable part, critical to your application.

Würth offers in-house specialty CAD services to our current customers, as an extension of our Engineering Support Services. In partnership with your Technical Application Specialist team, Würth can provide 2D and 3D drawings and models from physical samples, product scans, or a sketch. Our complete range of CAD services reduces your in-house engineering costs, eliminates freelance or contracted work on proprietary designs, and allows your Technical Application Specialists to focus on critical application work to decrease your time to market.

Current Würth customers can reach out to their Würth Technical Application Specialist, or contact Mark Allen at mark.allen@wurthindustry.com or (515) 306-5037.

If you are interested in our CAD services but are not a Würth customer, please contact us.

Service Offerings

New 2D Drawings

  • Sample to 2D Drawing
  • Scan to CAD
  • Napkin Sketch

Modify 2D Drawings

  • REV Change
  • Format Update
  • Missing Information

Product Inserts

  • Product Identification Templates
CAD Part next to drawing

Our Technical Application Specialists

Würth Technical Application Specialists are experts in providing customer support and act as a full-service, on-demand, extension of our customers’ in-house engineering department. Our Technical Application Specialists provide a range of value-added services and focus on delivering cost savings and design, efficiency, and safety improvements. With over 700 years of combined experience and a breadth of areas of expertise, the Würth Technical Application Specialist Team provides meaningful and beneficial partnerships to our customers.

Learn more about Engineering Assistance here.
